Real-Time UML (RTUML) refers to the application of the Unified Modelling Language (UML) for the analysis, design, and implementation of real-time and embedded systems, where timing constraints, concurrency, and resource management are critical. It extends standard UML with profiles, notations, and semantics to handle hard and soft real-time requirements, such as modelling predictable response times and fault tolerance. RTUML is not a separate language but a methodology leveraging UML diagrams (e.g., statecharts, sequence diagrams) for time-sensitive applications like automotive controls, avionics, and medical devices. The term is closely associated with Bruce Powel Douglass, who popularised it through his books and the Harmony process for embedded software development. As of 2025, RTUML remains relevant in industries requiring certified systems, though its adoption varies with agile methodologies and model-driven engineering tools. == Background == Real-Time UML emerged in the late 1990s as UML was standardized by the Object Management Group (OMG) in 1997, addressing the need for object-oriented modeling in real-time systems previously dominated by procedural languages like C. Traditional real-time development relied on "bare metal" programming or theoretical models, but RTUML introduced visual notations for object structure, behaviour, and timing. Bruce Powel Douglass’s 1999 book, Real-Time UML: Developing Efficient Objects for Embedded Systems, formalised the approach, emphasising statecharts for concurrency and timing constraints. Later editions (2004, 2006) incorporated UML 2.0 features like activity and timing diagrams, aligning with OMG’s Real-Time Profile (now part of MARTE—Modelling and Analysis of Real-Time and Embedded Systems). The Harmony process integrates RTUML with executable models for simulation and code generation. RTUML addresses hard real-time systems (e.g., strict deadlines in avionics) versus soft real-time (e.g., media streaming), using UML extensions for schedulability analysis. == Key concepts == RTUML adapts UML diagrams and techniques for real-time needs: Statecharts and Behaviour Modelling: Extended state machines model reactive behaviour, using and-states for concurrency, pseudostates for transitions, and timing constraints (e.g., {duration < 10ms}). Examples include cardiac pacemaker models. Sequence and Interaction Diagrams: Capture message timing, priorities, and resource allocation in multi-threaded systems. Architectural Patterns: Define logical and physical architectures with active objects for concurrency and patterns like observer or publisher-subscriber. Timing and Constraints: Use Object Constraint Language (OCL) for specifying deadlines and priorities. Profiles and Extensions: OMG’s UML Profile for Schedulability, Performance, and Time (SPT) and MARTE add stereotypes like RT::ActiveObject. These support iterative development, from requirements to deployment, often with tools like IBM Rhapsody or Enterprise Architect. == Applications == RTUML is used in: Embedded Systems: Modelling automotive ECUs or UAV controls. Avionics and Defence: DO-178C-compliant designs for fault tolerance. Medical Devices: Pacemakers or ventilators with precise timing. Industrial Automation: RTOS task visualisation via sequence diagrams. Tools like IBM Rhapsody support RTUML for model-based development and code generation in C/C++. == Criticism and adoption == RTUML’s complexity can overwhelm simple systems, and its use in agile environments is limited, where lightweight diagrams are preferred. Surveys indicate UML (including RTUML) is used in 30–50% of embedded projects, often for documentation rather than full model-driven engineering. It remains standard in academia and certified industries like aerospace.
Software diagnosis
Software diagnosis (also: software diagnostics) refers to concepts, techniques, and tools that allow for obtaining findings, conclusions, and evaluations about software systems and their implementation, composition, behaviour, and evolution. It serves as means to monitor, steer, observe and optimize software development, software maintenance, and software re-engineering in the sense of a business intelligence approach specific to software systems. It is generally based on the automatic extraction, analysis, and visualization of corresponding information sources of the software system. It can also be manually done and not automatic. == Applications == Software diagnosis supports all branches of software engineering, in particular project management, quality management, risk management as well as implementation and test. Its main strength is to support all stakeholders of software projects (in particular during software maintenance and for software re-engineering tasks) and to provide effective communication means for software development projects. For example, software diagnosis facilitates "bridging an essential information gap between management and development, improve awareness, and serve as early risk detection instrument". Software diagnosis includes assessment methods for "perfective maintenance" that, for example, apply "visual analysis techniques to combine multiple indicators for low maintainability, including code complexity and entanglement with other parts of the system, and recent changes applied to the code". == Characteristics == In contrast to manifold approaches and techniques in software engineering, software diagnosis does not depend on programming languages, modeling techniques, software development processes or the specific techniques used in the various stages of the software development process. Instead, software diagnosis aims at analyzing and evaluating the software system in its as-is state and based on system-generated information to bypass any subjective or potentially outdated information sources (e.g., initial software models). For it, software diagnosis combines and relates sources of information that are typically not directly linked. Examples: Source-code metrics are related with software developer activity to gain insight into developer-specific effects on software code quality. System structure and run-time execution traces are correlated to facilitate program comprehension through dynamic analysis in software maintenance tasks. == Principles == The core principle of software diagnosis is to automatically extract information from all available information sources of a given software projects such as source code base, project repository, code metrics, execution traces, test results, etc. To combine information, software-specific data mining, analysis, and visualization techniques are applied. Its strength results, among various reasons, from integrating decoupled information spaces in the scope of a typical software project, for example development and developer activities (recorded by the repository) and code and quality metrics (derived by analyzing source code) or key performance indicators (KPIs). == Examples == Examples of software diagnosis tools include software maps and software metrics. == Critics == Software diagnosis—in contrast to many approaches in software engineering—does not assume that developer capabilities, development methods, programming or modeling languages are right or wrong (or better or worse compared to each other): Software diagnosis aims at giving insight into a given software system and its status regardless of the methods, languages, or models used to create and maintain the system. === Related subjects === Cost estimation in software engineering Programming productivity Rapid application development Software design Software development Software documentation Software map Software release life cycle Systems design Systems Development Life Cycle
National Parking Platform
The National Parking Platform is a digital platform in the United Kingdom providing interoperability between car park operators, parking apps, and other service providers. It enables all parking apps that support the system: RingGo, JustPark, PayByPhone, Apcoa Connect, AppyParking, and Caura to work at all participating car parks. It has been rolled out in 13 local authorities so far. It was first developed by the Department for Transport starting in 2019, and since May 2025 is controlled by the British Parking Association on a not-for-profit basis. == Participating local authorities == Buckinghamshire Cheshire West and Chester Coventry City East Hertfordshire East Suffolk Liverpool City Manchester City Oxfordshire County Peterborough City Stevenage Sutton Walsall Welwyn Hatfield
System Service Descriptor Table
The System Service Descriptor Table (SSDT) is an internal dispatch table within Microsoft Windows. == Function == The SSDT maps syscalls to kernel function addresses. When a syscall is issued by a user space application, it contains the service index as parameter to indicate which syscall is called. The SSDT is then used to resolve the address of the corresponding function within ntoskrnl.exe. In modern Windows kernels, two SSDTs are used: One for generic routines (KeServiceDescriptorTable) and a second (KeServiceDescriptorTableShadow) for graphical routines. A parameter passed by the calling userspace application determines which SSDT shall be used. == Hooking == Modification of the SSDT allows to redirect syscalls to routines outside the kernel. These routines can be either used to hide the presence of software or to act as a backdoor to allow attackers permanent code execution with kernel privileges. For both reasons, hooking SSDT calls is often used as a technique in both Windows kernel mode rootkits and antivirus software. In 2010, many computer security products which relied on hooking SSDT calls were shown to be vulnerable to exploits using race conditions to attack the products' security checks.
Micro stuttering
Micro stuttering is a visual artifact in real-time computer graphics in which the time intervals between consecutively displayed frames are uneven, even though the average frame rate reported by benchmarking software appears adequate. Tools such as 3DMark typically compute frame rates over intervals of one second or more, which can conceal momentary drops in the instantaneous frame rate that the viewer perceives as hitching or jerking of on-screen motion. At low frame rates the effect is visible as a stutter in moving images, degrading the experience in interactive applications such as video games. In severe cases a lower but more consistent frame rate can appear smoother than a higher but more erratic one. The term gained prominence in the late 2000s in discussions of multi-GPU rendering (see History), but micro stuttering also affects single-GPU systems. Common causes on modern hardware include real-time shader compilation, asset streaming from storage, VRAM exhaustion, and driver bugs. == Causes == === Shader compilation === A common cause of micro stuttering on modern PCs is real-time shader compilation. Shaders are small programs that instruct the GPU on how to render visual effects such as lighting, shadows, and reflections. On consoles, developers can pre-compile all shaders for the known, fixed hardware. On PCs, the variety of GPU architectures means shaders must often be compiled at run time, either when the game launches or during gameplay itself. When the rendering engine encounters a shader that has not yet been compiled, the CPU must finish the compilation before the GPU can draw the affected object. This causes a spike in frame time that the player perceives as a hitch. The problem has been particularly associated with games built on Unreal Engine 4 running under DirectX 12, because DX12 shifts more shader management responsibility to the application. Several techniques exist to reduce shader compilation stutter. Pipeline State Object (PSO) pre-caching records the shader permutations used at runtime so that they can be compiled in advance on subsequent launches. Asynchronous shader compilation moves the work to background CPU threads to avoid blocking the main rendering thread. Platform-level services such as Steam's shader pre-caching distribute previously compiled shaders to users with matching GPU hardware. The Steam Deck, which contains a single fixed GPU, benefits from pre-compiled shader caches because all units share the same hardware configuration. === Other causes === Micro stuttering on single-GPU systems can have several additional causes. CPU bottlenecks or scheduling interruptions from background tasks can prevent the processor from preparing frames at regular intervals. Asset streaming during gameplay (loading textures, geometry, or audio from storage) can produce hitches sometimes called traversal stutter; the use of solid-state drives and technologies such as DirectStorage has reduced but not eliminated this. VRAM exhaustion forces data to be swapped between video memory and system memory over the PCI Express bus, which is slower. Graphics driver bugs can also introduce stutter; Nvidia released hotfix driver 551.46 in February 2024 to correct intermittent micro stuttering when V-Sync was enabled. == Measurement == Micro stuttering drew attention to the limitations of average frame rate as a performance metric. In 2013, Scott Wasson at The Tech Report published a series of articles advocating frame time analysis, in which the delivery time of every individual frame is recorded and plotted rather than collapsed into a single frames-per-second figure. This approach was adopted by other hardware review publications in the following years. GPU reviews now routinely report 1% low and 0.1% low frame rates alongside the average. The 1% low is the average frame rate of the slowest 1% of frames in a sample; it serves as an indicator of worst-case smoothness. A large gap between the average and the 1% low suggests poor frame pacing. Tools for capturing per-frame timing data include FRAPS, PresentMon, OCAT, CapFrameX, and MSI Afterburner with RivaTuner Statistics Server. == Mitigation == === Frame pacing === Frame pacing is a software technique that regulates the timing of frame delivery to produce even intervals between displayed frames. Game engines, GPU drivers, and platform libraries all implement frame pacing strategies to varying degrees. On mobile platforms, Google provides the Android Frame Pacing library (Swappy) as part of the Android Game Development Kit. In December 2025, the Khronos Group published the VK_EXT_present_timing Vulkan extension, giving developers explicit control over presentation timing in a cross-platform graphics API for the first time. === Variable refresh rate === Variable refresh rate (VRR) display technologies allow a monitor's refresh rate to change to match the GPU's frame output. Implementations include Nvidia G-Sync (2013), AMD FreeSync (2015), and the VESA Adaptive-Sync standard built into DisplayPort 1.2a and later. VRR eliminates the screen tearing that results from a mismatch between frame rate and refresh rate, and avoids the frame-holding behaviour of V-Sync that can itself cause stutter. It is effective at smoothing moderate frame rate fluctuations but cannot compensate for large sudden spikes in frame time such as those caused by shader compilation or heavy asset streaming. VRR support has become standard in gaming monitors, televisions (via HDMI 2.1), and the Xbox Series X/S and PlayStation 5 consoles. === Frame generation === Beginning with DLSS 3 on the GeForce RTX 40 series in 2022, Nvidia introduced AI-based frame generation, which uses dedicated optical flow hardware and a neural network to create new frames between traditionally rendered ones. AMD followed with FSR 3 in 2023, using an algorithmic approach, and the AI-based FSR 4 for the Radeon RX 9000 series in 2025. DLSS 4, released in January 2025 for the GeForce RTX 50 series, can generate up to three frames per rendered frame using a technique called Multi Frame Generation. Frame generation increases the displayed frame rate but introduces its own frame pacing concerns. If the underlying rendered frames are unevenly timed, the interpolated frames can make the unevenness more apparent rather than less. DLSS 4 addresses this with hardware-level flip metering on the GPU's display engine, which controls the timing of frame presentation more precisely than the CPU-based pacing used in DLSS 3. Both vendors pair frame generation with latency-reduction features (Nvidia Reflex and AMD Anti-Lag+) to offset the additional input latency that results from inserting synthetic frames into the pipeline. === Frame rate limiters === Capping the frame rate below the display's maximum refresh rate, using tools such as RivaTuner Statistics Server, in-game limiters, or driver-level settings, is a common way to improve frame pacing. Preventing the GPU from running ahead of the display reduces variability in frame delivery times and can produce a smoother result than an uncapped but more irregular frame rate. == History == === Multi-GPU configurations === Micro stuttering was first widely documented in the late 2000s as a side effect of multi-GPU configurations using Alternate Frame Rendering (AFR), in which consecutive frames are assigned to alternating GPUs. Because each GPU may take a different amount of time to complete its assigned frame — due to varying scene complexity, driver scheduling, or inter-GPU communication overhead — the resulting frame delivery is irregular even when the average frame rate is high. Both Nvidia SLI and AMD CrossFireX were affected, with dual-GPU setups exhibiting the worst frame pacing irregularities. In 2012 benchmarks using Battlefield 3, dual Radeon HD 7970 cards in CrossFire showed 85% variation in frame delivery times compared with 7% for a single card, while dual GeForce GTX 680 cards in SLI showed only 7% variation compared with 5% for a single card. Multi-GPU micro stuttering became a significant factor in the eventual decline and discontinuation of consumer multi-GPU gaming. Nvidia restricted SLI to a handful of enthusiast-class cards from the GeForce 10 series onward, then replaced it with NVLink on the GeForce RTX 20 series, which saw limited gaming adoption. AMD ceased active CrossFire development around 2017. By the mid-2020s, neither vendor's current consumer GPUs support multi-GPU rendering for games. Other factors that contributed to the decline include DirectX 12 placing multi-GPU support in the hands of game developers rather than driver authors, the incompatibility of temporal anti-aliasing and other temporal rendering techniques with AFR, and the increasing size, power draw, and cost of individual GPUs. The third-party utility RadeonPro could reduce CrossFire micro stuttering through dynamic V-Sync and frame pacing adjustments, and AMD later introduced a driver-level frame paci
Amazon Kinesis
Amazon Kinesis is a family of services provided by Amazon Web Services (AWS) for processing and analyzing real-time streaming data at a large scale. Launched in November 2013, it offers developers the ability to build applications that can consume and process data from multiple sources simultaneously. Kinesis supports multiple use cases, including real-time analytics, log and event data collection, and real-time processing of data generated by IoT devices. == History == Amazon Kinesis was launched by Amazon Web Services (AWS) in November 2013 as a managed service for processing and analyzing real-time streaming data at a large scale. The service was introduced to address the growing need for businesses to process and analyze data as it was generated, rather than in batches, allowing for real-time insights and decision-making. Since its launch, the Amazon Kinesis family of services has expanded to include four main components: Kinesis Data Streams, Kinesis Data Firehose, Kinesis Data Analytics, and Kinesis Video Streams. Each of these components serves a specific purpose in the processing and analysis of real-time streaming data. In August 2015, AWS announced the availability of Kinesis Data Firehose, a fully managed service for delivering real-time streaming data to destinations such as Amazon S3, Amazon Redshift, and Amazon Elasticsearch. A year later in August 2016, AWS launched Kinesis Data Analytics, enabling customers to analyze streaming data in real time using standard SQL queries. AWS introduced Kinesis Video Streams, a fully managed service for securely capturing, processing, and storing video streams for analytics and machine learning applications, was introduced by AWS in November 2017. == Components == Amazon Kinesis is composed of four main services: Kinesis Data Streams, Kinesis Data Firehose, Kinesis Data Analytics, and Kinesis Video Streams. === Kinesis Data Streams === Kinesis Data Streams is a scalable and durable real-time data streaming service that captures and processes gigabytes of data per second from multiple sources. It enables the storage and processing of data in real time, making it useful for applications that require immediate insights, such as monitoring and alerting. === Kinesis Data Firehose === Kinesis Data Firehose is a fully managed service for delivering real-time streaming data to destinations such as Amazon S3, Amazon Redshift, Amazon Elasticsearch, and AWS-partner data stores. With Data Firehose, users can configure and scale data delivery without manual intervention. === Kinesis Data Analytics === Kinesis Data Analytics enables the analysis of streaming data in real time using standard SQL or Apache Flink. === Kinesis Video Streams === Kinesis Video Streams is a fully managed service for securely capturing, processing, and storing video streams for analytics and machine learning. It supports multiple video codecs and streaming protocols, making it suitable for various use cases, such as security and surveillance, video-enabled IoT devices, and live event broadcasting. == Integration == Amazon Kinesis can be easily integrated with other AWS services, such as AWS Lambda, Amazon S3, Amazon Redshift, and Amazon OpenSearch. This integration enables developers to build end-to-end streaming data processing applications, taking advantage of the extensive AWS ecosystem. == Use cases == Some common use cases for Amazon Kinesis include: Real-time analytics: Analyzing streaming data in real time to provide immediate insights and make data-driven decisions. Log and event data collection: Collecting, processing, and analyzing log and event data generated by applications, infrastructure, and devices. IoT data processing: Processing and analyzing large volumes of data generated by IoT devices in real time. Machine learning: Ingesting and processing video streams for machine learning applications, such as object recognition, facial recognition, and sentiment analysis. == Pricing == Amazon Kinesis follows a pay-as-you-go pricing model, with costs depending on the chosen service, data volume, and processing power required. AWS provides a free tier for Kinesis Data Streams and Kinesis Data Firehose, allowing users to get started with the services at no cost.
ISO/IEC JTC 1/SC 24
ISO/IEC JTC 1/SC 24 Computer graphics, image processing and environmental data representation is a standardization subcommittee of the joint subcommittee ISO/IEC JTC 1 of the International Organization for Standardization (ISO) and the International Electrotechnical Commission (IEC), which develops and facilitates standards within the field of computer graphics, image processing, and environmental data representation. The international secretariat of ISO/IEC JTC 1/SC 24 is the British Standards Institute (BSI) located in the United Kingdom. == History == ISO/IEC JTC 1/SC 24 was formed in 1987 from ISO/TC 97 as a result of Resolution 21 at the ISO/IEC JTC 1 plenary. The group's origins began in computer graphics, the standardization of which was originally under ISO/IEC JTC 1/SC 21/WG 2. However, when ISO/IEC JTC 1/SC 24 was created, the standardization activity of ISO/IEC JTC 1/SC 21/WG 2 was carried over to the new subcommittee. The initial five working groups of ISO/IEC JTC 1/SC 24 were titled, “Architecture,” “Application programming interfaces,” “Metafiles and interfaces,” “Language bindings,” and “Validation, testing and registration.” The work of ISO/IEC JTC 1/SC 24 began with the Graphical Kernel System (GKS), which was adopted from ISO/IEC JTC 1/SC 21/WG 2. However, since GKS only addressed 2D functionality, attention turned to the standardization of 3D functionality. This resulted in two standards being published: GKS-3D in 1988 and PHIGS in 1989, both of which addressed 3D functionality. Since 1991, ISO/IEC JTC 1/SC 24 has held plenaries in a number of countries, including the Netherlands, Germany, United States, France, Canada, Japan, Sweden, Korea, United Kingdom, Australia, and Czech Republic. == Scope == The scope of ISO/IEC JTC 1/SC 24 is the “Standardization of interfaces for information technology based applications relating to”: Computer graphics Image processing Environmental data representation Support for the Mixed and Augmented Reality (MAR) Interaction with, and visual representation of, information Included are the following related areas: Modeling and simulation and related reference models Virtual reality with accompanying augmented reality/augmented virtuality aspects and related reference models Application program interfaces Functional specifications Representation models Interchange formats, encodings and their specifications, including metafiles Device interfaces Testing methods Registration procedures Presentation and support for creation of multimedia, hypermedia, and mixed reality documents Excluded are the following areas: Character and image coding Coding of multimedia, hypermedia, and mixed reality document interchange formats JTC 1 work in user system interfaces and document presentation ISO/TC 207 work on ISO 14000 environment management, ISO/TC 211 work on geographic information and geomatics Software environments as described by ISO/IEC JTC 1/SC 22 == Structure == ISO/IEC JTC 1/SC 24 is made up of four active working groups, each of which carries out specific tasks in standards development within the field of computer graphics, image processing and environmental data representation, together with ITU-T Study Group 16. As a response to changing standardization needs, working groups of ISO/IEC JTC 1/SC 24 can be disbanded if their area of work is no longer applicable, or established if new working areas arise. The focus of each working group is described in the group's terms of reference. Active working groups of ISO/IEC JTC 1/SC 24 are: == Collaborations == ISO/IEC JTC 1/SC 24 works in close collaboration with a number of other organizations or subcommittees, both internal and external to ISO or IEC, in order to avoid conflicting or duplicative work. Organizations internal to ISO or IEC that collaborate with or are in liaison to ISO/IEC JTC 1/SC 24 include: ISO/IEC JTC 1/WG 7, Sensor Networks ISO/IEC JTC 1/SC 29, Coding of audio, picture, multimedia and hypermedia information ISO/IEC JTC 1/SC 32, Data management and interchange ISO/TAG 14, Imagery and technology ISO/TC 130, Graphic Technology ISO/TC 184/SC 4, Industrial data ISO/TC 211, Geographic information/Geomatics ISO/TC 215, Health informatics IEC TC 100, Audio, video and multimedia system and equipment Some organizations external to ISO or IEC that collaborate with or are in liaison to ISO/IEC JTC 1/SC 24 include: Defence Geospatial Information Working Group (DGIWG) Digital Imaging and Communications in Medicine (DICOM) International Hydrographic Organization (IHO) The Khronos Group NATO - Joint Intelligence Surveillance and Reconnaissance Capability Group (JISRCG) OMG Robotics DTF Open CGM Open Geospatial Consortium (OGC) SEDRIS Organization Simulation Interoperability Standards Organization (SISO) US National Imagery Transmission Format Standard (NITFS) Technical Board (US NTB) Web3D Consortium World Intellectual Property Organization (WIPO) World Wide Web Consortium (W3C) == Member countries == Countries pay a fee to ISO to be members of subcommittees. The 11 "P" (participating) members of ISO/IEC JTC 1/SC 24 are: Australia, China, Egypt, France, India, Japan, Republic of Korea, Portugal, Russian Federation, United Kingdom, and United States. The 22 "O" (observer) members of ISO/IEC JTC 1/SC 24 are: Argentina, Austria, Belgium, Bosnia and Herzegovina, Bulgaria, Canada, Cuba, Czech Republic, Finland, Ghana, Hungary, Iceland, Indonesia, Islamic Republic of Iran, Italy, Kazakhstan, Malaysia, Poland, Romania, Serbia, Slovakia, Switzerland, and Thailand. == Published standards == ISO/IEC JTC 1/SC 24 currently has 80 published standards under their direct responsibility within the field of computer graphics, image processing, and environmental data representation, including:
